*This charger is only compatible with TE590/TE590P.
MUC-590/580/390
Multi Unit Charger
Multi Unit Charger
MUC-590/580/390 is a multi-way unit charger and a special design for Telo TE590/TE580/TE390, which can support up to 8pcs of devices charging simultaneously.
Key Benefits
Universal international full range AC input.
Power consumption lower than 0.2w when unloaded.
Embedded with short-circuit, over-loading protection
unit.
Maximum 1.5A output to each charging slot
Technical Information
Power Supply Specification
Voltage: 100V - 240V 50/60Hz AC 3A
Output: 15V 8A
Operating Temperature: 0oC +45oC
Storage Temperature: -20oC +70oC
Voltage: 100V - 240V 50/60Hz AC 3A
Output: 15V 8A
Operating Temperature: 0oC +45oC
Storage Temperature: -20oC +70oC
Charger Slot Specification
Input: DC15V 8A
Output: 5V 1.5A
Operating Temperature: 0oC +45oC
Storage Temperature: -20oC +70oC
Input: DC15V 8A
Output: 5V 1.5A
Operating Temperature: 0oC +45oC
Storage Temperature: -20oC +70oC
